Description
The Phosphoric Acid Hose from Hongruntong Marine is engineered for high-performance transfer of concentrated phosphoric acid in demanding industrial and marine environments. Its specialized inner tube provides exceptional chemical resistance, maintaining integrity and flexibility under exposure to orthophosphoric acid at concentrations up to 85%. The multi-layer reinforcement ensures mechanical stability under internal pressure, suction, and bending loads, while the outer cover provides abrasion, UV, and environmental protection. Smooth bore design reduces crystallization risk and ensures consistent flow, making it ideal for terminals, fertilizer plants, and bulk transport systems.
Case Study: Inland Fertilizer Terminal Long Distance Transfer
An inland fertilizer terminal in South America required a long-distance phosphoric acid transfer hose capable of spanning over 80 meters from storage tanks to blending units. Previous hoses failed due to chemical degradation, internal crystallization, and structural collapse during suction operations. Downtime and hose replacement costs were significant, affecting production schedules.
Hongruntong Marine supplied Phosphoric Acid Hoses specifically designed for long-distance transfer. These hoses featured a chemically resistant inner tube, multiple spiral reinforcement layers for structural integrity, and a smooth bore to minimize crystallization. Heavy-duty outer covers protected against abrasion and environmental exposure, while customized end fittings ensured proper integration with existing piping and pumping systems.
After 15 months of continuous service, internal inspections confirmed that the hoses maintained structural and chemical integrity. Flow rates remained consistent, and maintenance downtime was reduced by 35%. The terminal reported zero contamination events due to hose wear, demonstrating that a purpose-built Phosphoric Acid Hose significantly improves operational reliability, product purity, and cost efficiency in long-distance industrial transfer applications.
Specifications
| Product Name | Phosphoric Acid Hose |
| Reinforcement | Multi Plies High Strength Synthetic Fabric |
| Cover | Epdm Resistant to Chemical, Weathering and Ozone, Blue, Green Wrapped |
| Size | 3/4"-6" or Customized Size |
| Certification | IS09001 |
| Temperature Range | -40°C to 120°C |
| Working Pressure | 10-16 bar |
| Length | According to Customer Demand, It is Generally 60 Meters |
| Application | Desigued for In-Plant or Tank Truck Use to Transfer Chemicals and Solvents |
| Features | Chemical Resistance, Good Pressure Resistance and Good Stability |
| Model | Inner Diameter (mm) | Outer Diameter (mm) | Working Pressure (bar) | Burst Pressure (bar) | Bend Radius (mm) | Max Temp (°C) | Min Temp (°C) | Length per Roll (m) |
| HM-PAH1 | 25 | 38 | 10 | 30 | 150 | 80 | -20 | 20 |
| HM-PAH2 | 32 | 46 | 10 | 30 | 180 | 80 | -20 | 20 |
| HM-PAH3 | 38 | 54 | 10 | 30 | 210 | 80 | -20 | 20 |
| HM-PAH4 | 50 | 68 | 10 | 30 | 280 | 80 | -20 | 20 |
| HM-PAH5 | 65 | 85 | 10 | 30 | 350 | 80 | -20 | 20 |
| HM-PAH6 | 75 | 97 | 10 | 30 | 400 | 80 | -20 | 20 |
| HM-PAH7 | 90 | 112 | 10 | 30 | 480 | 80 | -20 | 20 |
| HM-PAH8 | 100 | 125 | 10 | 30 | 550 | 80 | -20 | 20 |
| HM-PAH9 | 125 | 155 | 10 | 30 | 700 | 80 | -20 | 20 |
| HM-PAH10 | 150 | 185 | 10 | 30 | 850 | 80 | -20 | 20 |
Key Features
Specialized Inner Tube for High Concentration Phosphoric Acid
The inner tube is formulated to withstand aggressive phosphoric acid environments, retaining tensile strength, flexibility, and chemical resistance under prolonged exposure and elevated temperatures. It prevents liner degradation, softening, and contamination, ensuring consistent transfer performance.
Multi Layer Reinforcement for Structural Stability
Multiple spiral layers of synthetic fiber reinforcement provide resistance to internal pressure, vacuum, and mechanical stress. This prevents kinking, collapse, and deformation, ensuring reliable performance in both suction and pressure applications.
Smooth Bore for Efficient Flow
The smooth inner surface minimizes turbulence and prevents crystallization, ensuring consistent flow rates and reducing maintenance requirements. Optimized bore geometry also enhances pumping efficiency and reduces energy consumption.
Durable Outer Cover for Harsh Environments
The outer cover provides protection against abrasion, UV exposure, ozone, and environmental hazards. It ensures safe handling, preserves structural integrity, and maintains flexibility across temperature variations for reliable operation.
Applications
Long Distance Industrial Phosphoric Acid Transfer
Ideal for conveying phosphoric acid over extended distances between storage and processing units, maintaining chemical integrity and flow consistency.
Fertilizer Blending and Reactor Feed
Used to supply concentrated phosphoric acid to blending lines and high-temperature reactors, ensuring product purity and continuous operation without crystallization or degradation.
Bulk Terminal Loading and Unloading
Designed for terminal operations, the hose withstands suction, high-pressure pumping, and frequent handling while maintaining mechanical stability and chemical resistance.
Why Choose Hongruntong Marine
Expertise in Phosphoric Acid Hose Design
Hongruntong Marine specializes in hoses engineered for phosphoric acid, offering chemical compatibility, thermal resilience, and mechanical performance unmatched by general-purpose chemical hoses.
Tailored Solutions for Complex Operations
Custom assembly lengths, reinforcement levels, and fittings are provided to meet specific industrial and marine operational layouts, optimizing performance and service life.
Rigorous Testing and Quality Control
Hoses undergo extensive chemical, pressure, vacuum, and dimensional testing. Serial tracking ensures traceability, quality assurance, and operational reliability.
Proven Performance in Global Industrial Networks
Hongruntong hoses are used worldwide in fertilizer plants, terminals, and offshore operations. Clients benefit from reduced maintenance, extended hose lifespan, and reliable phosphoric acid transfer.
FAQ
1. Can this hose handle high-concentration phosphoric acid?
Yes, the Phosphoric Acid Hose is designed for concentrations up to 85%, maintaining chemical stability and mechanical integrity under prolonged use.
2. Is it suitable for suction and pressure applications?
Yes, the multi-layer reinforcement prevents collapse under vacuum and withstands internal pressure, ensuring reliable performance.
3. How should the hose be maintained?
Conduct regular inspections, follow bend radius recommendations, and flush the interior to prevent crystallization. Avoid prolonged exposure to direct heat or chemical spills.
4. Which fittings are compatible?
Stainless steel flanges, PTFE-lined couplings, and acid-resistant composite fittings can be used depending on operational requirements.
5. What is the expected service life of the hose?
With proper use and maintenance, the hose provides multiple years of reliable service, outperforming standard chemical hoses in durability, safety, and chemical resistance.
